SP2S13H20A SAW — OPERATION AND PARTS MANUAL — REV. #1 (05/17/10) — PAGE 51
LIFTING BALE ASSY.
NO PART NO PART NAME QTY. REMARKS
1 28890-351 13HP, LIFT BALE ASSY. 1
1 28890-352 20HP, LIFT BAIL ASSY. 1
2 28893-001 BRACE, 13HP BAIL 1
2 28893-002 BRACE, 20HP BAIL 1
3 0205 SCREW, HHC 3/8-16 X 1.0 2
4 10133 NUT, NYLOC 3/8-16 2
5 10136 WASHER, FLAT SAE 3/8 4
6 5283 NUT, NYLOC 5/16-18 2
7 0300 B WASHER, FLAT SAE 5/16 4
8 0202 SCREW, HHC 5/16-18 X 1 ZINC 2
LIFTING BALE ASSY.
