SP2S13H20A SAW — OPERATION AND PARTS MANUAL — REV. #1 (05/17/10) — PAGE 69
HYD. TRANSMISSION ENGAGE LEVER ASSY.
NO PART NO PART NAME QTY. REMARKS
1 28825-351 LEVER ASSY. TRANS. ENGAGE 1
2 3360 GRIP, 1/4 X 1 BLACK 1
3 28822-351 MOUNT ASSY., LEVER RED 1
4 0655 SCREW, HHC 5/16-18 X 3/4 4
5 10136 WASHER, FLAT SAE 3/8 6
6 6014 B PIN, COTTER 3/32D X 1.0 1
7 08326-005 PIN, CLEVIS 5/16 X 1 O’ALL LENGHT PLATED 2
8 07028-031 PIN, COTTER 3/32D X 1/2 2
9 5283 NUT, NYLOC 5/16-18 8
10 08326-019 PIN, CLEVIS 3/8 X 2” USEABLE LENGHT 1
11 2199 NUT, HEX JAM 3/8-24 2
12 08327-012 YOKE END, 3/8-24 X 2.50 2
13 28830-001 ROD, TRANS. ENGINE 1
14 28819-351 TRANS. BRACKET ASSY. 1
TRANSMISSION ENGAGE LEVER ASSY.
