SP2S13H20A SAW — OPERATION AND PARTS MANUAL — REV. #1 (05/17/10) — PAGE 71
h h
HYDROSTATIC TRANSMISSION ASSY.
NO PART NO PART NAME QTY. REMARKS
1 20559-001 SPRING, EXT. 3.38FL X 71OD X .105 1
2 1493 SCREW, HHC 3/8-18 X 3.25 4
3 28836-001 LINK, RETURN SPRING 1
4 10133 NUT, NYLOC 3/8-16 7
5 10136 WASHER, FLAT SAE 3/8 8
6 1023 SCREW, HHC 3/8-16 X 1 1/4 GR 5 2
7 15354 TRANSMISSION, HYD EATON 1
8 1578 KEY, WOODRUFF #3 2
9 0166 A WASHER, LOCK 3/8 MED. 4
10 1456 NUT, HEX FINISH 3/8-16 4
11 28828-351 SHIFT ARM ASSY. 1
12 28829-001 PIN, PIVOT 2
13 10450 SCREW, SHS 10-32 X 1/4 1
14 103530-000 CAP, TRANSMISSION 1
HYDROSTATIC TRANSMISSION ASSY.
