SP2S13H20A SAW — OPERATION AND PARTS MANUAL — REV. #1 (05/17/10) — PAGE 63
BLADE GUARD ASSY.
NO PART NO PART NAME QTY. REMARKS
1 29406-754 BLADE GUARD W/A - RED 1
2 28729-002 GUARD, SPLASH BLADE 1
3 60021 HOSE, 3/8ID X 5/8OD BRAIDED PVC “PAC” 1.670
4 0131 A SCREW, HHC 1/4-20 X 3/4 2
5 10024 NUT, NYLOC 1/4-20 2
6 24642-001 Y-CONNECTOR 3/8 1
7 12694-006 HOSE CLAMP, SPRING TYPE 3/4 O.D. HOSE 2
8 24778-001 FITTING, BRASS 1/2BARB X 3/4F GRDN 1
9 18626-001 SPRING TENSION, GUARD BLADE 2
10 22129-001 PIPE STRAP 3/8 2
11 21168 SCREW, HHC 3/8-16 X 4.75 1
12 0424 SCREW, HHC 1/4-20 X 1 1/4 4
13 0949 NUT, HEX FINISH 1/4-20 PLATED 4
14 0181 B WASHER, LOCK 1/4 MED. 4
15 0948 WASHER, FLAT SAE 1/4 6
17 0166 A WASHER, LOCK 3/8 MED. 2
18 10136 WASHER, FLAT SAE 3/8 2
BLADE GUARD ASSY.
