SP2S13H20A SAW — OPERATION AND PARTS MANUAL — REV. #1 (05/17/10) — PAGE 65
JACK SCREW ASSY. 20” BLADE
NO PART NO PART NAME QTY. REMARKS
1 28793-352 JACKPOST ASSY. 1
2 2621 ZERK, GREASE STR. 1/4-28 1
3 28806-001 JACKSCREW 1
4 28083-001 BEARING, FLANGE 1
5 28809-001 SPACER, JACKSCREW 1
6 4568 PIN, ROLL 3/16 X 1 1
7 28877-751 SCREW COVER ASSY., RED 1
8 1579 SCREW, HHC 1/4-20 X 1/2 3
9 0948 WASHER, FLAT SAE 1/4 7
10 0181 B WASHER, LOCK 1/4 MED. 3
11 0730 SCREW, HHC 1/4-20 X 1 2
12 1162 A CAP,GREASE ZERK, #2 1
13 10024 NUT, NYLOC 1/4-20 2
14 1121 SCREW, HHC 3/8-16 X 2 3/4 1
15 1876 NUT, HEX JAM 3/8-16 CLASS 2B 1
16 4403 KNOB, SHIFT 1
17 28808-002 ARM-CRANK 1
MANUAL RAISE AND LOWER ASSY. (20 IN. )
