FLeXSHaFTS/VIBRaTOR HeaDS • OpeRaTIOn anD paRTS manuaL — ReV. #0 (07/16/10) — page 21
nO. paRT nO. paRT name QTy. RemaRKS
1 314V2 FLEXSHAFT 24" (0.6 M) ...................................1................INCLUDES ITEM W/#
1 314V5 FLEXSHAFT 60" (1.5 M) ...................................1................INCLUDES ITEM W/$
1 314V7 FLEXSHAFT 84" (2.1 M) ...................................1................INCLUDES ITEM W/◊
1 314V10 FLEXSHAFT 120" (3 M) ....................................1................INCLUDES ITEM W/%
1 314V12 FLEXSHAFT 144" (3.7 M) .................................1................INCLUDES ITEM W/@
1 314V14 FLEXSHAFT 168" (4.3 M) .................................1................INCLUDES ITEM W/♦
1 314V18 FLEXSHAFT 216" (5.5 M) .................................1................INCLUDES ITEM W/♥
1 314V21 FLEXSHAFT 252" (6.4 M) .................................1................INCLUDES ITEM W/♣
2# 13609-502 CORE, 27-1/16" (.685 M) 1
2$ 13609-505 CORE, 63-1/16" (1.6 M) 1
2◊ 13609-507 CORE, 87-1/16" (2.2 M) 1
2% 13609-510 CORE, 123-1/16" (3.12 M) 1
2@ 13609-512 CORE, 147-1/16" (3.73 M) 1
2♦ 13609-514 CORE, 171-1/16" (4.34 M) 1
2♥ 13609-518 CORE, 219-1/16" (5.56 M) 1
2♣ 13609-521 CORE, 255-1/16" (6.47 M) 1
3 90004-03 SPINDLE, FEMALE ...........................................1................OPTION
4 90004-05 COUPLER, FEMALE .........................................1................OPTION
314V series flexible shafts assy.
NOTICE
Item 1 to be used only with a CV-1, 50/60 Hz, 115 VAC
1 HP, 10 amp electric motor only or a BP25H, 2.1 HP
gasoline engine. Reference Table 1
