HDA-SERIES WALK-BEHIND TROWEL — OPERATION AND PARTS MANUAL — REV. #9 (07/02/10) — PAGE 57
ENGINE, 11 HP HONDA ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 1388 ENGINE 11 HP HONDA 1
2 1391 HHCS 5/16-24 x 1-1/2" 4
3 0161 C LOCK WASHER 5/16" 4
4 0300 B FLAT WASHER 5/16" 4
5 0310 SQUARE KEY 1/4X1/4X1.1/2" 1
6 2480 CLUTCH, 4" P-G 35 DEGREE 1" 1
7 1488 WIRE, SAFETY SWITCH 1
8 1475 CONNECTOR, SPLICE TAP 1
9 0261 BELT, A31 GATES HPII ONLY 2
10 2362 SPACER, 1-1/4 X .878 X .375l 1
11 9119 PULLEY, HD48 2AK54X7/8 1
12 10222 GUARD, BELT 1
13 10136 LOCK WASHER 1/4" 2
14 2724 T-BOLT 2
15 9154 SCREW, HHC 3/8 - 16 X 1-3/4 2
16 0166 A WASHER, LOCK 3/8 MED 3
17 20982 SCREW, FSCS 3/8 - 16 X 1-1/2 PLTD 2
18 1480 WASHER, CS EXT. SHKP 3/8 2
19 1951 PLATE, FRONT, 11HP HONDA 2
20 1245 BUSHING, GUARD RING 4
21 1247 GROMMET, 1/4 X 7/8ID X 1-5/8OD 4
22 9123 RETAINER, CLUTCH 1
23 9120 RETAINER, DRIVEN PULLEY 1
24 0478 SCREW, HHC 3/8 -24 X 2-1/4 1
25 2361 SPACER, 1-1/4 X .878 X .437L 1
26 1313 SCREW, FHSC 3/8 - 24 X 3/4 PLAIN 1
27 LIFT STRAP ........................................................................... 1 .......... CONTACT UNIT SALES
............................................................................................................. DEPT./ACC. ITEM
