HDA-SERIES WALK-BEHIND TROWEL — OPERATION AND PARTS MANUAL — REV. #9 (07/02/10) — PAGE 103
NO. PART NO. PART NAME QTY. REMARKS
1 16271ZE2000 GASKET, ELBOW 1
2 17210ZE3505 ELEMENT, AIR CLEANER .......................... 1 ......... INCLUDES ITEMS W/ #
3 # 17218ZE3505 FILTER, OUTER 1
4 17231ZE3W00 COVER, AIR CLEANER .............................. 1 ......... USE UP TO ENGINE SN3125749
4 17231ZE3W01 COVER, AIR CLEANER 1
5 # 17232891000 GROMMET, AIR CLEANER 1
7 * 17238ZE2310 COLLAR, AIR CLEANER 2
8 * 17239ZE1000 COLLAR B, AIR CLEANER 1
9 17410ZH9N00 ELBOW, AIR CLEANER .............................. 1 ......... INCLUDES ITEMS W/ *
11 90203ZA0800 WINGNUT, 6MM 1
12 90325044000 WINGNUT, TOOL BOX SETTING 1
13 90009ZE2003 BOLT- WASHER 6X22 1
14 9405006000 NUT, FLANGE 6MM 2
HONDA GX390K1QA2— AIR CLEANER ASSY.
