HDA-SERIES WALK-BEHIND TROWEL — OPERATION AND PARTS MANUAL — REV. #9 (07/02/10) — PAGE 113
NO. PART NO. PART NAME QTY. REMARKS
1 12000ZF6W12 CYLINDER ASSEMBLY, ALERT ...................... 1 ......... INCLUDES ITEMS W/ *
...................................................................................... USE UP TO ENGINE SN 3020570
1 12000ZF6W13 CYLINDER ASSEMBLY, ALERT ...................... 1 ......... INCLUDES ITEMS W/ *
...................................................................................... USE FROM ENGINE SN 3020571
2 15510ZE2033 SWITCH ASSEMBLY, OIL LEVEL ................... 1 ......... USE UP TO ENGINE SN 2334667
2 15510ZE2043 SWITCH ASSEMBLY, OIL LEVEL ................... 1 ......... USE FROM ENGINE SN 2334668
3 16541ZE3010 SHAFT, GOVERNOR ARM 1
4 32197ZE2003 SUB-HARNESS ............................................... 1 ......... USE UP TO ENGINE SN 2334667
5 90013883000 BOLT, FLANGE 6X12 (CT200 .......................... 1 ......... USE UP TO ENGINE SN 2334667
6 90131896650 BOLT, DRAIN PLUG ......................................... 2
7 90446KE1000 WASHER 8.2X17X0.8 ...................................... 1
9 * 91201ZE3004 OIL SEAL 35X52X8 ......................................... 1
10 * 91201ZE9003 OIL SEAL 8X14X5 ........................................... 1
10 * 91203952771 OIL SEAL 8X14X5 ........................................... 1
11 91353671003 O- RING 13.5X1.5 (ARAI) ................................ 1
12 9405010000 NUT, FLANGE 10MM ....................................... 1
13 9410912000 WASHER, DRAIN PLUG 12MM ....................... 2
14 9425110000 PIN,LOCK 10MM ............................................. 1
15 957010601200 BOLT, FLANGE 6X12 ....................................... 2
16 * 961006202000 BEARING, RADIAL BALL 6202 ....................... 1
17 90013883000 BOLT, FLANGE 6X12 (CT200) ......................... 1 ......... USE FROM ENGINE SN 2468555
18 3415ZH7003 ALERT UNIT, OIL ............................................. 1 ......... USE FROM ENGINE SN 2468555
HONDA GX390K1QA2— CYLINDER BARREL ASSY.
