HDA-SERIES WALK-BEHIND TROWEL — OPERATION AND PARTS MANUAL — REV. #9 (07/02/10) — PAGE 45
STANDARD HANDLE ASSY. (NEW STYLE)
NO. PART NO. PART NAME QTY. REMARKS
1% 0786 SCREW, BHC 1/4-20 X 3/8 NYL PATCH ,NP 2
2% 0786A SPACER, SLIDE BLOCK GUIDE 1
3% 1116 NUT, BRASS JAM 5/16-18 2
4% 1284 SCREW, HHC 3/8-16 X 1 1/2 1
5% 3233 WASHER, FENDER, 1.5OD X 3/8ID 4
6% 9154 SCREW, HHC 3/8-16 X 1 3/4 2
7% 10133 NUT, NYLOC 3/8-16 2
8% 20285 CABLE, CONTROL 1
9% 20287 SLIDE BLOCK, TROWEL CONTROL 1
10% 20439 WHEEL ASM. , HAND 1
11% 20478 GRIP, HANDLE 2
12% 20514 WIRE ASSY., KILL SWITCH 1
13% 20819 HAND WHEEL ASSY, PITCH CONTROL ......................... 1 ......... INCLUDES ITEMS W/$
14% 20856 SWITCH ASM., KILL 1
15% 21171 THROTTLE, BICYCLE FINISHER HANDLES 1
16% 21172 CABLE, THROTTLE 68” 1
17% 21173 HOUSING, MAGURA THROTTLE CABLES 1
18% 22055 HANDLE WA, VIBRATION CONTROL 1
19% 22059 ISOLATOR, VIBRATION 80 DUROMETER SHORE A 3
20% 22095 HANDLE, W/A, STOW FIN VIBE CONTROL 1
21% 22166 COVER,VIBE CONTROL HANDLE PAD 1
22% 22167 SCREW, HHC 3/8-16 X 6.5” GRADE 5 1
23% 22206 CHASSIS, CAST VIBRATION ISOLATOR 1
24% 22256 BRACKET, HD KILLSWITCH MOUNT 2
25% 22263 SCREW, PHILLIPS HEAD MACHINE 8-32 X .75 4
26% 22226 KIT, INSTALLATION VIBE CONTROL HANDLE ................ 1 ......... INCLUDES ITEMS W/@
27%@ 20461 BLOCK, CABLE ASSY. .................................................... 1 ......... INCLUDES ITEMS W/#
28%@# 1118 PULLEY, SUPPORT BLOCK 1
29%@# 20460 BLOCK, SUPPORT 1
30%@# 20279 PIN, SUPPORT BLOCK 3/8 X 1.59 1
31%$ 20817 WHEEL, HAND HANDLE 1
32%$ 0281 BEARING, THRUST, NICE 607 1
33%$ 20282 BEARING, TROWEL CONTROL 1
34%$ 3615 COLLAR, SET 3/4 ID 1
35%$ 0122 C SCREW, SHS 3/8-16 X 1/2 1
36%$ 1478 SHAFT, TROWEL CONTROL 1
37%@ 10133 NUT, NYLOC 3/8-16 2
38%@ 10136 WASHER, FLAT 3/8 SAE 4
39%@ 0169 SCREW, HHC 3/8-16 X 3 4
40 22258 HANDLE ASSY, SXH HD .................................................. 1 ......... INCLUDES ITEMS W/%
