HDA-SERIES WALK-BEHIND TROWEL — OPERATION AND PARTS MANUAL — REV. #9 (07/02/10) — PAGE 51
QUICK-PITCH™ HANDLE ASSY. (NEW STYLE)
NO. PART NO. PART NAME QTY. REMARKS
1% 1116 NUT, BRASS JAM 5/16-18 2
2% 1665 SCREW, HHC 3/8-16 X 2 2
3% 1715 Q.P. SPRING CENTER BALANCE 1
4% 1717 SCREW, QP TRIM ADJUSTMENT W/A 1
5% 1718 NUT , QP TRIM CNTL ADJUSTMENT 1
6%@ 20389 HANDLE, QP 1
7%@ 1729 PIN, ROLL 3/16 X 1-1/4 2
8% 1732 Q.P. ADJUSTMENT PIN 1
9% 1733 WASHER, 1/2 X 1/32, AN960-816L 2
10% 1737 RING, SNAP, TRUARC 5100-50 1
11% 3233 WASHER, FENDER, 1.5OD X 3/8ID 4
12%# 4568 PIN, ROLL 3/16 x 1 1
13% 9154 SCREW, HHC 3/8-16 X 1 3/4 1
14% 10133 NUT, NYLOC 3/8-16 2
15% 20270 QP ADJUSTMENT BLOCK 1
16% 20293 LINKAGE QP CONTROL ........................................................... 1 .................. INCLUDES ITEMS W/#
17% 20390 TRIGGER, QP ASSEMBLY ........................................................ 1 .................. INCLUDES ITEMS W/@
18% 20439 WHEEL ASM. , HAND 1
19% 20478 GRIP, HANDLE 2
20% 20514 WIRE ASSY., KILL SWITCH 1
21% 20856 SWITCH ASM., KILL 1
22% 21171 THROTTLE, BICYCLE FINISHER HANDLES 1
23% 21172 CABLE, THROTTLE 68” 1
24% 21173 HOUSING, MAGURA THROTTLE CABLES 1
25% 20297 CABLE ASM, LENGTH 45", JB, HD & QP 1
26% 22055 HANDLE WA, VIBRATION CONTROL 1
27% 22059 ISOLATOR, VIBRATION 80 DUROMETER SHORE A 3
28% 22060 MAIN HANDLE WA,QUICK PITCH VIBE CONTROL 1
29% 22166 COVER,VIBE CONTROL HANDLE PAD 1
30% 22167 SCREW, HHC 3/8-16 X 6.5” GRADE 5 1
31% 22206 CHASSIS, CAST VIBRATION ISOLATOR 1
32%@ 1711 SHAFT, CONTROL Q.P. 1
33% 22256 BRACKET, HD KILLSWITCH MOUNT 1
34% 22263 SCREW, PHILLIPS HEAD MACHINE 8-32 X .75 2
35% 22226 KIT, INSTALLATION VIBE CONTROL HANDLE ......................... 1 .................. INCLUDES ITEMS W/$
36%@ 12405 DECAL, WHITEMAN QUICK PITCH 2
37%@ 1729 PIN, ROLL 3/16 X 1-1/4 1
38%@ 1724 GRIP, HANDLE 1
39%@ 1706 SPRING, COMPRESSION 1
40%@ 20437 PIN, QP LATCH 1
41%@ A6581 TRIGGER, QP 1
42%# 1731 PIN, ROLL 1/4 X 3/4 1
43%# 20443 ARM, SLIDE CONTROL 1
44%# 1709 QP DOGBONE 1
45%# 20269 BLOCK, CABLE SLIDE 1
46%# 20276 PIN, ROLL 1/4 X 1-3/4 1
47%$& 22095 HANDLE, W/A, STOW FIN VIBE CONTROL 1
48%$& 20279 PIN, SUPPORT BLOCK 3/8 X 1.59 1
49%$& 1118 PULLEY, SUPPORT BLOCK 1
50%$& 0169 SCREW, HHC 3/8-16 X 3 4
51%$ 10136 WASHER, FLAT 3/8 SAE 4
52%$ 10133 NUT, NYLOC 3/8-16 2
53%$ 20461 BLOCK, CABLE ASSY. ............................................. 1............... INCLUDES ITEMS W/&
54 22257 HANDLE ASSY, QXH HD ........................................................... 1 .................. INCLUDES ITEMS W/%
