C-4 FINISHER WALK-BEHIND TROWEL — PARTS & OPERATION MANUAL — REV. #1 (07/24/02) — PAGE 15
C-4 FINISHER TROWEL— GENERAL INFORMATION
C-4 Trowel Finisher Familiarization
This walk-behind finisher is designed for the floating and
finishing of concrete slabs.
Take a walk around the trowel. Take notice of all the major
components (see Figure 3, page16) like the engine, blades,
Quick Pitch™ handle, clutch lever, etc. Check that there is always
oil in the engine.
Read all the safety instructions carefully. Safety instructions will
be found throughout this manual and on the trowel. Keep all
safety information in good, readable condition. Operators should
be well trained on the operation and maintenance of the trowel.
Before using your trowel, test it on a flat watered down section of
finished concrete that is free of any debris and other objects.
This trial test run will increase your confidence in using the trowel
and at the same time it will familiarize you with the trowel’s
controls. In addition you will understand how the trowel handles
under actual conditions.
Engines
This trowel is available with an 2.5 HP HONDA gasoline engine.
Refer to the engine owner’s manual for instructions regarding
the operation and maintenance of your engine. The engine
manual is included with your trowel at the time of shipping from
Whiteman. Please contact your nearest Multiquip Dealer for a
replacement should the original manual disappear.
Drive System
Power is transferred from the engine to the gearbox input shaft
via a V-belt pulley drive system. The pulley engages using a
manual clutch. See parts section of this manual.
Gearbox
The gearbox is located beneath the engine and transfers power
to the spider assembly. The gearbox controls the rotational speed
of the trowel and is equipped with two shafts (input and output).
Spider
The vertical output shaft of the gearbox connects to a cast hub
called the
spider . The spider has 4 arms that extend outward
that are used for attachment of blades or other accessories.
Remember as the gearbox output shaft rotates so does the spider
assembly.
NEVER attempt to lift the trowel by yourself.
ALWAYS get the assistance of another
person to help lift the trowel .
Moving the Trowel
This trowel is light weight, however for safety purposes always
use
two people to lift the trowel up onto a slab of concrete.
Training
For proper training, please use the “TRAINING CHECKLIST”
located in the front of this manual (Page 6). This checklist will
provide an outline for an experienced operator to provide training
to a new operator
CAUTION CAUTION CAUTION CAUTION CAUTION
Blades
The blades of the trowel finish the concrete as they are rotated
around the surface. Blades are classified as
combination (8
inches wide), float (10 or 8 inches wide), and finish (6 inches
wide). This trowel comes equipped with four blades per
rotor equally spaced in a radial pattern and attached to
vertical rotating shaft by means of a
spider assembly.
Manual Clutch
In the event of a trowel runaway condition (operator releases
the handle), a
manual clutch will stop the engine and bring
the trowel to a halt.
