PAGE 12 — MAYCO LS300P CONCRETE PUMP • OPERATION MANUAL — REV. #0 (06/09/14)
Table 1. Pump Specifications
Model LS300P
Pumping Rate Up to 30 cu. yds. per hour*
Pumping Method Reciprocating Piston
Maximum Aggregate Size 1-1/2 in. minus (38 mm)
Vertical Pumping Height Up to Excess of 200 ft. (60.9 m)
Piston Face Pressure 800 PSI (55.16 bar)
Horizontal Pumping Distance 800 ft. (243m)*
Cylinder Lubrication Box Capacity 2 Gallons (7.6 Liters)
Hydraulic Fluid Capacity 33 Gallons (125 Liters)
Fuel Tank Capacity 16 Gallons (61 Liters)
Hopper Capacity 10 cu. ft.
Material Hose
3 in., 4 in., 5 in. dia.
(76.2mm, 101.6 mm, 127 mm)
Engine Model
Perkins Turbo
Diesel 404D-22TA
Weight (with fluids) 3,750 lbs. (1,701 kg)
Tire Size ST 225/75 R15
Options Wireless Remote Control, Hopper Screen Vibrator
* Volume output will vary depending on mix design, slump, line size used and job site conditions
SPECIFICATIONS
Table 2. Engine Specifications
Model Perkins Turbo Diesel 404D-22TA
Type 4 stroke, Water-Cooled Diesel
No. of Cylinders 4
Bore x Stroke
3.31 in. x 3.94 in.
(84 mm x 100 mm)
Rated Output 64.2 HP@ 2400 rpm
Displacement 135.2 cu. in. (2.2 L)
Starting Electric 12VDC
Lube Oil Capacity 9.4 qt. (8.9 liters)
Coolant Capacity/With Radiator 3.8 qt. (3.8 liters)
Fuel Type #2 Diesel Fuel
Battery 12V BCI Group 27
Weight Dry 1,250 lbs. (567 kg)
Dimensions LxWxH in. (mm)
50 x 28.9 x 37.9
(1,269 x 734 x 964)
