WBH16/WBH16e poWer Buggy (S/n 110401 & up)• operaTion and parTS manual — rev. #0 (06/14/11) — page 59
fuel assy.
no. parT no. parT name qTy. remarKS
1 492622 WASHER, LOCK 1/4 IN. 5
2 492356 SCREW, 1/4 x 3/4 IN. G5 4
3 509161 WASHER, FLAT 1/4 IN. 4
5 520820 CAP, FUEL (EPA) 1
7 506208 CLAMP, FUEL HOSE 4
9 19633 SEAL, FUEL TANK GROMMET 1
10 20795 VALVE, FUEL SHUT-OFF 1
11 60013 HOSE, FUEL EPA 1/4" AR
12 20763 FILTER, FUEL 2
14 511807 STRAP NYLON 5/8 1
15 515386 COVER, FUEL TANK 1
16 800845 SECTION COVER, FUEL TANK 1
17 800841 TANK, FUEL 1
18 23507 GROMMET, FUEL VALVE 1
19 23508 VALVE, FUEL 1
20 517621 CLAMP 2
21 60004 HOSE, FUEL EPA 3/16" AR
22 23505 CANNISTER, CHARCOAL 390CC 1
23 510725 CLAMP 2
24 492355 SCREW, 1/4 NC X 1/2 IN. G5 1
25 60028 HOSE, FUEL EPA 5/16" AR
AR — AS REQUIRED
20763
