WBH16/WBH16e poWer Buggy (S/n 110401 & up)• operaTion and parTS manual — rev. #0 (06/14/11) — page 41
no. parT no. parT name qTy. remarKS
1 492472 SCREW, ALLEN HEAD 3/8-16 X 3/4 2
2 511719 COUPLING, ENGINE SHAFT 1
4 18112 FAN 1
6 492596 WASHER, FLAT 1/4" 2
7 492355 SCREW, HHC 1/4-20 X 1/2 2
11 506250 KEY, WOODRUFF 1
20 512494 FAN GUARD 1
21 512493 BRACKET, LONG 1
22 512505 BRACKET, SHORT 1
23 492373 BOLT, C/H 3/8" NC X 3/4" G5 1
24 492624 WASHER, LOCK 3/8 IN. 1
25 512367 BOLT, C/H 3/16" NC X 1/2" G2 4
26 492595 WASHER, FLAT 3/16 IN. 4
27 492621 WASHER, LOCK 3/16 IN. 4
28 492438 BOLT, C/H 5/16" NF X 1" G5 1
29 492623 WASHER, LOCK 5/16" 1
puMp and COuplinG assy.
