WBH16/WBH16e poWer Buggy (S/n 110401 & up)• operaTion and parTS manual — rev. #0 (06/14/11) — page 49
no. parT no. parT name qTy. remarKS
1 18132 LEVER, THROTTLE 1
2 492581 NUT, NYLOC 1/4-20 1
3 492582 NUT, NYLOC 5/16-18 1
4 491030 WRAP, T1z 1
5 504505 WRAP, T1E 1
6 18025 SWITCH, KILL 1
7 18242 HANDLE BAR 1
8 511432 GRIP, HANDLE 2
9 18181 BUSHING, CABLE 1
10 18177 SPRING 1
11 511717 KEY, WOODRUFF 1/8X5/8 1
12 18061 LEVER, CONTROL 1
13 512414 SCREW, HHC 1/4-20 X 2-1/4 1
14 492561 NUT, HEX 1/4-20 2
15 492584 NUT, NYLOC 1/2-13 1
16 492357 SCREW, HHC 1/4-20X1 1
17 18183 CONNECTOR, THROTTLE CABLE END 2
18 18176 SPRING 1
19 18182 BUSHING, CABLE 1
20 18133 CABLE, THROTTLE 1
21 492465 SCREW, ALLEN HEAD 1/4-20 X3/8 1
22 506088 SCREW, HHC 1/4-20X3/8 1
23 492369 SCREW, HHC 5/16-18X2-1/4 1
24 491723 PIN, STEERING SHAFT 1
25 18238 BUSHING, STEERING SHAFT 2
26 512186 PIN, STEERING SHAFT 1
27 18091 AXLE, STEERING 1
28 EM941306 HUB, REAR WHEEL ..........................................2................INCLUDES ITEMS W/ #
29 EM501299 WASHER, REAR WHEEL HUB 2
30 512210 NUT, CASTLE 2
31 491688 PIN, COTTER 1/8 X 1-1/2 2
32 18049 WHEEL, STEERING ASSY. REAR 2
33 8115 NUT LUG 8
34 511159 WASHER, FLAT 1 IN. 2
35# EM903113 BEARING CONE 2
36# 15191VB SEAL 1
37 512200 BUSHING, BRONzE 2
steerinG assy.
