ga6HR/6HRS 60 hz gENERATOR • OpERATiON ANd pARTs mANuAl — REv. #0 (08/12/14) — pAgE 13
Table 2. specifications (Engine)
Engine
model hONdA gX340RT2EdN2 hONdA gX340RT2EdE2
Type
Air-cooled 4 stroke, Single Cylinder, OHV, Horizontal Shaft
Gasoline Engine
Bore X Stroke
3.46 in. X 2.52 in.
(88 mm x 64 mm.)
Displacement 23.70 cu-in (389 cm 3 )
Max Output 11.0 H.P./3600 R.P.M.
Fuel Unleaded Automobile Gasoline
Lube Oil Capacity 1.16 quarts (1.1 liters)
Oil Alert System Yes
Speed Control Method Centrifugal Fly-weight Type
Starting Method Recoil Start Electric Start
dimensions
(l x W x h)
15.0 x 17.7 X 17.4 in.
(380 X 450 X 443 mm)
15.0 x 17.7 X 17.4 in.
(380 X 450 X 443 mm)
dry Net Weight 68.4 lbs. (31 kg.) 68.4 lbs. (31 kg.)
SPECIFICATIONS (ENGINE)
Effects of Altitude and heat
The maximum output of the engines listed above are applicable to supplying electrical power for continuous service at
ambient conditions in accordance with SAE Test cord J607. The above ambient conditions are at standard sea level, with
a barometric reading of 29.92 inches and a temperature of 60° F (15.5° C).
Generally, the engine's output power will decrease 3-1/2% for each 1000 feet (305 meters) of altitude above sea level, and
1% for each 10° F (-12.2° C) above the standard temperature of 60° F (15.5° C).
