QP-204H CENTRIFUGAL PUMP — OPERATION AND PARTS MANUAL— REV. #3 (06/05/06) — PAGE 61
HONDA GX120K1PX2/GX120U1PX2 ENGINE — RECOIL STARTER ASSY.
RECOIL STARTER ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 28400ZH8013ZB STARTER ASSY., RECOIL *NH1* (BLACK) .......... 1 .............. INCLUDES ITEMS W/ %
1 , , , , , 28400ZH8023ZB STARTER ASSY., RECOIL *NH1* (BLACK) .......... 1 .............. INCLUDES ITEMS W/#
2 % # 28410ZH8003ZB CASE, RECOIL STARTER 1
3 % 28420ZH8013 REEL, RECOIL STARTER 1
3 , , , , ,# 28421ZH8801 REEL, RECOIL STARTER 1
4 % 28422ZH8013 RATCHET, STARTER 2
4 , , , , ,# 28422ZH8801 RATCHET, STARTER 2
5 % 28433ZH8003 GUIDE, RATCHET 1
5 , , , , ,# 28431ZH8801 GUIDE, RATCHET 1
6 % 28441ZH8003 SPRING, FRICTION 1
6 , , , , ,# 28433ZH8801 SPRING, FRICTION 1
7 % 28442ZH8003 SPRING, RECOIL STARTER 1
7 , , , , ,# 28441ZH8801 SPRING, RECOIL STARTER 1
8 % 28443ZH8003 SPRING, RETURN 2
8 , , , , ,# 28442ZH8003 SPRING, RETURN 2
9 % 28461ZH8003 KNOB, RECOIL STARTER 1
9 , , , , ,# 28443ZH8801 KNOB, RECOIL STARTER 1
10 % 28462ZH8003 ROPE, RECOIL STARTER 1
10 , , , , ,# 28461ZH8003 ROPE, RECOIL STARTER 1
11 % 90003ZH8003 SCREW, SETTING 1
11 , , , , ,# 28462ZH8003 SCREW, SETTING 1
12 90008ZE2003 BOLT, FLANGE 6X10 3
NOTE GX120K1PX2: Model QP-204H S/N 204H-19761 AND BELOW
, , , , , GX120U1PX2: Model QP-204H S/N 204H-19762 AND ABOVE
