QP-204H CENTRIFUGAL PUMP — OPERATION AND PARTS MANUAL— REV. #3 (06/05/06) — PAGE 59
PISTON ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 13010ZE6013 RING SET, PISTON (STANDARD) .............. 1 ........... S/N 3284616 AND BELOW
1 13010ZK7V01 RING SET, PISTON (STANDARD) .............. 1 ........... S/N 3284617 AND ABOVE
1 13011ZE6013 RING SET, PISTON (OS 0.25) ................... 1 ........... S/N 3284616 AND BELOW
1 13011ZK7V01 RING SET, PISTON (OS 0.25) ................... 1 ........... S/N 3284617 AND ABOVE
1 13012ZE6013 RING SET, PISTON (OS 0.50) ................... 1 ........... S/N 3284616 AND BELOW
1 13012ZK7V01 RING SET, PISTON (OS 0.50) ................... 1 ........... S/N 3284617 AND ABOVE
1 13013ZE6013 RING SET, PISTON (0.75) .......................... 1 ........... S/N 3284616 AND BELOW
1 13013ZK7V01 RING SET, PISTON (0.75) .......................... 1 ........... S/N 3284617 AND ABOVE
1 , , , , , 13010ZE6013 RING SET, PISTON (STANDARD) 1
1 , , , , , 13010ZK7V01 RING SET, PISTON (STANDARD) 1
1 , , , , , 13011ZE6013 RING SET, PISTON ( 0.25) 1
1 , , , , , 13011ZK7V01 RING SET, PISTON ( 0.25) 1
1 , , , , , 13012ZE6013 RING SET, PISTON ( 0.50) 1
1 , , , , , 13012ZK7V01 RING SET, PISTON ( 0.50) 1
1 , , , , , 13013ZE6013 RING SET, PISTON (0.75) 1
1 , , , , , 13013ZK7V01 RING SET, PISTON (0.75) 1
2 13101ZH7000 PISTON, STANDARD 1
2 13102ZH7000 PISTON, OS 0.25 1
2 13103ZH7000 PISTON, OS 0.50 1
2 13104ZH7000 PISTON, 0.75 1
3 13111ZE0000 PIN, PISTON 1
4 132A0ZE0000 ROD ASSEMBLY, CONNECTING ............... 1 ........... INCLUDES ITEM W/ #
(UNDER SIZE)
4 13200ZE0000 ROD ASSEMBLY, CONNECTING ............... 1 ........... INCLUDES ITEM W/ #
5 # 90001ZE1000 BOLT, CONNECTING ROD 2
6 90551ZE0000 CLIP, PISTON PIN 13MM 2
HONDA GX120K1PX2/GX120U1PX2 ENGINE— PISTON ASSY.
NOTE GX120K1PX2: Model QP-204H S/N 204H-19761 AND BELOW
, , , , , GX120U1PX2: Model QP-204H S/N 204H-19762 AND ABOVE
