QP-204H CENTRIFUGAL PUMP — OPERATION AND PARTS MANUAL— REV. #3 (06/05/06) — PAGE 47
CYLINDER HEAD ASSY.
NO.
PART NO.
PART NAME
QTY.
REMARKS
1
12210ZH7000
CYLINDER HEAD .................................................. 1 .............. INCLUDES ITEMS W/
%
1
,
,
,
,
,
12210ZH7405
CYLINDER HEAD .................................................. 1 .............. INCLUDES ITEMS W/
#
2
%
12204ZE1306
GUIDE, VALVE (OS) OPTIONAL
1
3
%
12205ZE1315
GUIDE, EX. VALVE (OS) OPTIONAL ................... 1 .............. INCLUDES ITEMS W/
+
4
%
+
12216ZE5300
CLIP, VALVE GUIDE
1
5
12251ZH7800
GASKET, CYLINDER HEAD
1
6
12310ZE1000
COVER, HEAD ...................................................... 1 .............. S/N 3909674 AND BELOW
6
12310ZE1020
COVER, HEAD ...................................................... 1 .............. S/N 3909675 AND ABOVE
6
,
,
,
,
,
12310ZE1020
COVER, HEAD
1
7
12391ZE1000
GASKET, CYLINDER HEAD COVER
1
8
15721ZH8000
TUBE, BREATHER
1
9
90013883000
BOLT, FLANGE 6X12 (CT200)
4
10
90043ZE1020
BOLT, STUD 6X109
2
11
90047ZE1000
BOLT, STUD 8X32
2
12
9430110160
PIN, A, DOWEL 10X16
2
14
957230805500
BOLT, FLANGE 8X55
4
15
9807955846
SPARK PLUG BPR5ES (NGK), OPTIONAL
1
15
9807956846
SPARK PLUG BPR5ES (NGK)
1
15
,
,
,
,
,
9807955855
PLUG, SPARK(W16EPR-U) (DENSO)
1
15
,
,
,
,
,
9807956855
PLUG, SPARK(W20 EPR-U) (DENSO)
1
HONDA GX120K1PX2/GX120U1PX2 ENGINE— CYLINDER HEAD ASSY.
NOTE
GX120K1PX2: Model QP-204H S/N 204H-19761 AND BELOW
,
,
,
,
, GX120U1PX2: Model QP-204H S/N 204H-19762 AND ABOVE
