QP-204H CENTRIFUGAL PUMP — OPERATION AND PARTS MANUAL— REV. #3 (06/05/06) — PAGE 49
HONDA GX120K1PX2/GX120U1PX2 ENGINE— FAN COVER ASSY.
RECOIL STARTER ASSY.
NO.
PART NO.
PART NAME
QTY.
REMARKS
1
1134371300
GROMET, ADJUSTING CABLE
1
2
19610ZE0000ZE
COVER, FAN
*
NH1
*
BLACK
1
3
19612ZH7810
PLATE, SIDE(OIL ALERT) .................................... 1 .............. S/N 3084882 AND BELOW
3
19612ZH7811
PLATE, SIDE(OIL ALERT) .................................... 1 .............. S/N 3084883~3182937
3
19612ZH7812
PLATE, SIDE(OIL ALERT) .................................... 1 .............. S/N 3182938~3257376
3
19611ZH7810
PLATE, SIDE(OIL ALERT) .................................... 1 .............. S/N 3257377 AND ABOVE
3
,
,
,
,
,
19611ZH7810
PLATE, SIDE(OIL ALERT)
1
4
19613ZE1010
CLAMP, CORD ...................................................... 1 .............. S/N 2867760 AND BELOW
4
90601ZH7013
CLIP, HARNESS .................................................... 1 .............. S/N 2867761 AND ABOVE
4
,
,
,
,
,
90601ZH7013
CLIP, HARNESS
1
5
19630ZH7000
SHROUD
1
6
32197ZH8003
SUB, HARNESS
1
7
36100ZE1015
SWITCH ASSEMBLY, ENGINE STOP .................. 1 .............. S/N 2867760 AND BELOW
7
36100ZH7003
SWITCH ASSEMBLY, ENGINE STOP .................. 1 .............. S/N 2867761 AND ABOVE
7A
,
,
,
,
,
36100ZF6P81
SWITCH ASSEMBLY, ENGINE STOP
1
8
36101ZE1010
WIRE, STOP SWITCH 370MM
1
9
90013883000
BOLT, FLANG 6 X 12 (CT200)
6
10
90022888010
BOLT, FLANG 6 X 12 (CT200)
1
11
34150ZH7003
ALERT UNIT, OIL .................................................. 1 .............. S/N 3259629 AND ABOVE
13
957010600800
BOLT, FLANGE 6X8 .............................................. 3 .............. S/N 3259269 AND ABOVE
NOTE
GX120K1PX2: Model QP-204H S/N 204H-19761 AND BELOW
,
,
,
,
, GX120U1PX2: Model QP-204H S/N 204H-19762 AND ABOVE
