QP-204H CENTRIFUGAL PUMP — OPERATION AND PARTS MANUAL— REV. #3 (06/05/06) — PAGE 53
FUEL TANK ASSY.
NO.
PART NO.
PART NAME
QTY.
REMARKS
1
16854ZH8000
RUBBER, SUPPORTER 107MM
1
2
16955ZE1000
JOINT, FUEL TANK
1
3
17510ZE0020ZD
TANK, FUEL *NH1* (BLACK)
1
4
17620Z0T305
CAP COMP., FUEL TANK
5
17620ZH7023
CAP, FUEL FILTER ..................................... 1 .......... INCLUDES ITEMS W/
#
5
,
,
,
,
,
17620Z0T305
CAP, FUEL FILTER ..................................... 1 .......... INCLUDES ITEMS W/
%
6
#
17631ZH7003
GASKET, FUEL FILLER CAP
1
6
,
,
,
,
,
%
17631Z0T812
GASKET, FUEL FILLER CAP
1
11
91353671003
O- RING 13.5X1.5 (ARAI)
1
11
,
,
,
,
,
91353671004
O- RING 14MM (NOK)
1
12
9405006000
NUT, FLANGE 6MM
2
13
950014500360M
BULK HOSE, FUEL (4.5X3000) (4.5X140) 1
13
,
,
,
,
,
950014514040
BULK HOSE, FUEL (4.5X3000) (4.5X140) 1
14
9500202080
CLIP, TUBE (B8)
2
15
957010602500
BOLT, FLANGE 6X25 .................................. 1 .......... S/N 3890882 AND BELOW
15
90004ZH7003
BOLT, FLANGE 6X29 .................................. 1 .......... S/N 3890883 AND ABOVE
15
,
,
,
,
,
90004ZH7003
BOLT, FLANGE 6X29
1
HONDA GX120K1PX2/GX120U1PX2 ENGINE— FUEL TANK ASSY.
NOTE
GX120K1PX2: Model QP-204H S/N 204H-19761 AND BELOW
,
,
,
,
, GX120U1PX2: Model QP-204H S/N 204H-19762 AND ABOVE
