MVH-120GH — OPERATION AND PARTS MANUAL — REV. #03 (10/24/07) — PAGE 67
HONDA GX160 ENGINE — FUEL TANK ASSY.
NOTE
GX160K1SM12: MODEL MVH120G S/N F-1104 (1998-2004)
,
,
,
,
, GX160U1SM12: MODEL MVH120G S/N F-1105 (2005)
+
+
+
+
+ GX160U1SMX4: MODEL MVH120G S/N P-4378 AND ABOVE (2006 )
FUEL TANK ASSY.
NO
PART NO
PART NAME
QTY.
REMARKS
1
17620Z0T305
CAP COMP., CHROME PLATED............... 1 ......... INCLUDES ITEM W/
#
1
, +
, +
, +
, +
, +
17620Z0T305
CAP COMP., CHROME PLATED............... 1 ......... S/N 1125014 AND BELOW
............................................................................. INCLUDES ITEM W/+
1
, +
, +
, +
, +
, +
17620Z4H000
CAP COMP., CHROME PLATED............... 1 ......... S/N 1125015 AND ABOVE
............................................................................. INCLUDES ITEM W/
%
2
#
17631Z0T812
PACKING, FUEL FILLER CAP
1
2
,+
,+
,+
,+
,++
17631Z0T812
PACKING, FUEL FILLER CAP .................. 1 ......... S/N 1125014 AND BELOW
2
,+
,+
,+
,+
,+
%
17631Z0T801
PACKING, FUEL FILLER CAP .................. 1 ......... S/N 1125015 AND ABOVE
3
17672ZE2W01
FILTER, FUEL
1
3
, +
, +
, +
, +
, +
17672ZE2W01
FILTER, FUEL ........................................... 1 ......... S/N 1125014 AND BELOW
3
, +
, +
, +
, +
, +
117672Z4H000
FILTER, FUEL ........................................... 1 ......... S/N 1125015 AND ABOVE
4 +
+
+
+
+
17510ZE1020ZF
FUEL TANK COMP.
1
4
,
,
,
,
,
17510ZE1020ZF
FUEL TANK COMP. ................................... 1 ......... S/N 1137417 AND BELOW
4
,
,
,
,
,
17510ZE1030ZF
FUEL TANK COMP. ................................... 1 ......... S/N 1137418 AND ABOVE
5
9405006000
FLANGE NUT 6 MM
2
6
90004ZH7003
BOLT, FLANGE 6X29
1
7
91353671003
O-RING 14 MM .......................................... 1 ......... REPLACES 91353671004
8
16955ZE1000
JOINT, FUEL TANK
1
9
9500202080
CLIP, TUBE
2
9
, +
, +
, +
, +
, +
9500202080
CLIP, TUBE ................................................ 2 ......... S/N 1031487 AND BELOW
9
, +
, +
, +
, +
, +
950024080008
CLAMP, TUBE ........................................... 2 ......... S/N 1031488 AND ABOVE
10
950014514040
TUBE, FUEL 4.5X140
1
10
,+
,+
,+
,+
,+
90014514040
TUBE, FUEL 4.5X140 ............................... 1 ......... S/N 1031487 AND BELOW
10
,+
,+
,+
,+
,+
91424Z4F801
TUBE, FUEL 4.5X140 ............................... 1 ......... S/N 1031488 AND ABOVE
11
16854ZH8000
RUBBER, SUPPORT (107 MM)
1
