MVH-120GH — OPERATION AND PARTS MANUAL — REV. #03 (10/24/07) — PAGE 59
HONDA GX160 ENGINE — FAN COVER ASSY.
GX160K1SM12: MODEL MVH120G S/N F-1104 (1998-2004)
,
,
,
,
, GX160U1SM12: MODEL MVH120G S/N F-1105 (2005)
+
+
+
+
+ GX160U1SMX4: MODEL MVH120G S/N P-4378 AND ABOVE (2006 )
NOTE
FAN COVER ASSY.
NO
PART NO
PART NAME
QTY.
REMARKS
1
19610ZE1000ZC
COVER COMP., FAN NH1
1
1
, +
, +
, +
, +
, +
19610ZE1000ZC
COVER COMP., FAN NH1 ............... 1 ...... S/N 1120542 AND BELOW
1
, +
, +
, +
, +
, +
19610ZE1010ZC
COVER COMP., FAN NH1 ............... 1 ...... S/N 1120543 AND ABOVE
2
19630ZH8000
SHROUD COMP.
1
3
36100ZH7003
SWITCH ASSY. ENGINE STOP
1
3
, +
, +
, +
, +
, +
36100ZF6P81
SWITCH ASSY. ENGINE STOP ...... 1 ...... S/N 1145482 AND BELOW
3
, +
, +
, +
, +
, +
36100ZF6P82
SWITCH ASSY. ENGINE STOP ...... 1 ...... S/N 1145483 AND ABOVE
4
90013883000
BOLT, FLANGE 6X12
6
5
90022888010
BOLT, FLANGE 6X20
1
6
90601ZH7013
CLIP, HARNESS
1
7
19611ZH8810
PLATE COMP., SIDE OIL ALERT
1
8
34150ZH7003
ALERT UNIT, OIL
1
8
, +
, +
, +
, +
, +
34150ZH7003
ALERT UNIT, OIL ............................. 1 ...... S/N 1145270 AND BELOW
8
, +
, +
, +
, +
, +
34150ZH7013
ALERT UNIT, OIL ............................. 1 ...... S/N 1145271 AND ABOVE
9
957010600800
BOLT, FLANGE 6X8
1
