MVH-120GH — OPERATION AND PARTS MANUAL — REV. #03 (10/24/07) — PAGE 63
HONDA GX160 ENGINE — AIR CLEANER ASSY.
NOTE
GX160K1SM12: MODEL MVH120G S/N F-1104 (1998-2004)
, , , , , GX160U1SM12: MODEL MVH120G S/N F-1105 (2005)
+
+ + + + GX160U1SMX4: MODEL MVH120G S/N P-4378 AND ABOVE (2006 )
AIR CLEANER ASSY.
NO PART NO PART NAME QTY. REMARKS
1 16271ZE1000 PACKING, ELBOW 1
2 17210ZE1505 CLEANER ELEMENT .................. 1 .......... INCLUDES ITEMS W/ #
................................................................. REPLACES 17210ZE1822
3 # 17218ZE1505 OUTER ELEMENT ...................... 1 .......... REPLACES 17218ZE1821
4 17230ZE1820 COVER, AIR CLEANER 1
5 # 17232891000 GROMET, AIR CLEANER 1
6 , , , , , 17235ZE1831 NOSE, SILENCER 1
7 % 17238ZE7010 COLLAR, AIR CLEANER 2
8 % 17239ZE1000 COLLAR (B), AIR CLEANER 1
9 17410ZE1020 ELBOW COMP., AIR CLEANER . 1.......... INCLUDES ITEMS W/ %
10 90325044000 NUT 2
11 9405006000 NUT, FLANGE 6MM 2
12 957010602000 BOLT, FLANGE 6X20 1
