MVH-120GH — OPERATION AND PARTS MANUAL — REV. #03 (10/24/07) — PAGE 53
HONDA GX160 ENGINE — PISTON ASSY.
GX160K1SM12: MODEL MVH120G S/N F-1104 (1998-2004)
,
,
,
,
, GX160U1SM12: MODEL MVH120G S/N F-1105 (2005)
+
+
+
+
+ GX160U1SMX4: MODEL MVH120G S/N P-4378 AND ABOVE (2006)
NOTE
PISTON ASSY.
NO
PART NO
PART NAME
QTY.
REMARKS
1
13010ZL0003
RING SET, PISTON (STD)
1
1
, +
, +
, +
, +
, +
13010ZL0003
RING SET, PISTON (STD) ...................... 1 ......... S/N 1120413 AND BELOW
1
, +
, +
, +
, +
, +
13010Z4K004
RING SET, PISTON (STD) ...................... 1 ......... S/N 1120414 AND ABOVE
1
13011ZL0003
RING SET, PISTON (0.25)
1
1
, +
, +
, +
, +
, +
13011Z4K004
RING SET, PISTON (0.25) ...................... 1 ......... S/N 1120413 AND BELOW
1
, +
, +
, +
, +
, +
13011ZL0003
RING SET, PISTON (0.25) ...................... 1 ......... S/N 1120414 AND ABOVE
1
13012ZH0003
RING SET, PISTON (0.50) ...................... 1 .........
1
, +
, +
, +
, +
, +
13012ZL0003
RING SET, PISTON (0.50) ...................... 1 ......... S/N 1120413 AND BELOW
1
, +
, +
, +
, +
, +
13012Z4K004
RING SET, PISTON (0.50) ...................... 1 ......... S/N 1120414 AND ABOVE
1
13013ZH0003
RING SET, PISTON (0.75)
1
1
, +
, +
, +
, +
, +
13013ZL0003
RING SET, PISTON (0.75) ...................... 1 ......... S/N 1120413 AND BELOW
1
, +
, +
, +
, +
, +
13013Z4K004
RING SET, PISTON (0.75) ...................... 1 ......... S/N 1120414 AND ABOVE
2
13101ZH8010
PISTON (STD)
1
2
, +
, +
, +
, +
, +
13101ZH8010
PISTON (STD) ........................................ 1 ......... S/N 1120413 AND BELOW
2
, +
, +
, +
, +
, +
13101ZH8020
PISTON (STD) ........................................ 1 ......... S/N 1120414 AND ABOVE
2
13102ZH8010
PISTON (0.25) ......................................... 1
2
, +
, +
, +
, +
, +
13102ZH8010
PISTON (0.25) ......................................... 1 ......... S/N 1120413 AND BELOW
2
, +
, +
, +
, +
, +
13102ZH8020
PISTON (0.25) ......................................... 1 ......... S/N 1120414 AND ABOVE
2
13103ZH8010
PISTON (0.50) ......................................... 1
2
, +
, +
, +
, +
, +
13103ZH8010
PISTON (0.50) ......................................... 1 ......... S/N 1120413 AND BELOW
2
, +
, +
, +
, +
, +
13103ZH8020
PISTON (0.50) ......................................... 1 ......... S/N 1120414 AND ABOVE
2
13104ZH8010
PISTON (0.75)
1
2
, +
, +
, +
, +
, +
13104ZH8010
PISTON (0.75) ......................................... 1 ......... S/N 1120413 AND BELOW
2
, +
, +
, +
, +
, +
13104ZH8020
PISTON (0.75) ......................................... 1 ......... S/N 1120414 AND ABOVE
3
13111ZE1000
PISTON PIN
1
4
13200ZE1010
ROD ASSY., CONNECTING ................... 1 ......... INCLUDES ITEM W/
#
4
132A0ZE1000
ROD ASSY., CONNECTING ................... 1 ......... 0.25 UNDER SIZE (OPTION)
5
#
90001ZE1000
BOLT, CONNECTING ROD
2
6
90551ZE1000
CLIP, PISTON PIN 18 MM
2
