MVH-120GH — OPERATION AND PARTS MANUAL — REV. #03 (10/24/07) — PAGE 55
HONDA GX160 ENGINE — CAMSHAFT ASSY.
GX160K1SM12: MODEL MVH120G S/N F-1104 (1998-2004)
, , , , , GX160U1SM12: MODEL MVH120G S/N F-1105 (2005)
+
+ + + + GX160U1SMX4: MODEL MVH120G S/N P-4378 AND ABOVE (2006)
NOTE
CAMSHAFT ASSY.
NO PART NO PART NAME QTY. REMARKS
1 14100ZE1812 CAMSHAFT ASSY. ................................. 1 ......... INCLUDES ITEM W/ #
3 14410ZE1010 ROD, PUSH 2
5 14431ZE1000 ARM, VALVE ROCKER 2
6 14441ZE1010 LIFTER, VALVE 2
7 14451ZE1013 PIVOT, ROCKER ARM 2
8 # 14568ZE1000 SPRING, WEIGHT RETURN 1
9 14711ZF1000 VALVE, INLET 1
10 14721ZF1000 VALVE, EXHAUST 2
11 14751ZF1000 SPRING, VALVE 1
12 14771ZE1000 RETAINER, INTAKET VALVE 1
13 14773ZE1000 RETAINER, EXHAUST VALVE 1
14 14781ZE1000 ROTATOR, VALVE 1
15 14791ZE1010 PLATE, PUSH ROD GUIDE 1
16 90012ZE0010 BOLT, PIVOT 8 MM 2
17 90206ZE1000 NUT, PIVOT ADJUSTING 2
18 14781ZE1000 SEAL, VALVE STEM 1
18 ,+ ,+ ,+ ,+ ,+ 12209ZH8003 SEAL, VALVE STEM 1
