Specifications:
1.1 Main dimensions
RW 1504 /HF/HK/FK/HFK Drum width 850 mm Drum width 630 mm
Working width: mm 850 630
Overall width mm 850 630
Overall length mm 1770 1770
Overall height mm 1200 1200
Distance between axles mm 850 850
Drum diameter mm 500 500
Weights:
Intrinsic weight: kg 1413 1341
Operational weight: kg 1480 1408
Mean axle load: kg 740 704
Drive system:
Engine/Type: Hatz 2G40 Hatz 2G40
Output: kW/PS 13.2 / 18 13.2 / 18
At rpm: 2700 2700
No. of cylinders/cooling: 2 / air cooled 2 / air cooled
Battery: V 12 12
Ah 72 72
Drive mode: hydrostatic hydrostatic
Driven drums: 4 4
Vibration system:
Centrifugal
force: Vibration forwards: kN
82 82
Vibration reverse: kN
Amplitude: Vibration forwards: mm
2,2 2,2
Vibration reverse: mm
Frequency: Vibration forwards: Hz
30 30
Vibration reverse: Hz
Drive mode: hydrostatic hydrostatic
Vibrating drums: 4 4
Brakes:
Service brake: hydrostatic hydrostatic
Parking brake: hydromechanical hydromechanical
