Operation:
7.0 Jump start device (FSE)
Note:
12 V system!!!
1. Connect the jump start battery to the „+“ terminal and
the „+“ terminal of the FSE to the machine.
2. Connect the jump start battery to the „-“ terminal and
the „-“ terminal of the FSE to the machine.
3. Start the machine (page 26, section 6.1) Start
procedure
4. Disconnect the battery again in the reverse order.
Remark:
In order to avoid danger when connecting and
disconnecting the battery,
connect the „+“ terminal fi rst and disconnect it last. The „-“
terminal should never be connected alone.
8.0 Loading and transport
• To load the roller using hoisting gear, there is a central transport eye bolt „B“ in the middle of the roller (Fig. 28).
• The roller can also be loaded independently by being driven up a suitable loading ramp.
Note:
• Only loading ramps with suffi cient loading capacity and static stability must be used which exclude any possibility of
personal injury.
• To lash the roller, always use shackles which are fastened to the transportation eye bolts „O“ (at the front and back
of the central web).
• The roller must be lashed in such a way that it is secured against tipping over, slipping or rolling away.
• Do not walk or stand under suspended loads.
