Operation:
4.2 Back-up safety bar
Forward travel: No function!
Reverse travel: If the back-up safety bar is actuated,
the machine automatically comes to an
immediate stop.
Moving clear: Move Both travel levers „FR“ and
„FL“ to the „front“ position, the
machine travels away from the
obstacle!
4.3 Engine safety support
Used for fi lling the fuel tank or when the engine hood
is opened to carry out repairs. The hood is safeguarded
against dropping by the gas pressure spring.
i Danger
The engine hood falling down can lead to serious
injury!
The gas compression spring must not be removed
and must always replaced in order to exclude the
danger of injury..
4.4 Address setting
• Open cover D.
• Loosen plug „S-A“ on the transmitter and receiver.
(Fig. 13-15)
• Using a screwdriver, it is then possible to set
up to four addresses.
Note:
• The addresses at the transmitter and receiver
must correspond.
• Example: 0 - 0/9 - 9 etc.
