Operation:
Note:
• The minimum distance between the transmitter (operator) and the receiver (machine) is 2 metres. If the
the minimum distance is not adhered to, the safety close-range function is activated, i.e. the machine
cannot be started.
• If the minimum distance is not adhered to during operation, the engine continues to run but the machine
comes to a standstill. In both cases, increase the distance and repeat the process.
• If several machines are in use at the same location, the addresses must be coordinated.
i Danger
Switching errors or malfunctions can be caused as a result of identical frequencies!!!
5.4 Switching on and reversing the direction of travel
• Travel levers „FL“ and „FR“ in „front“ position: Machine travels forwards.
• Travel levers „FL“ and „FR“ in „back“ position: Machine travels backwards.
• If the travel levers are moved in opposite directions, the machine travels around its vertical axis (on the spot).
• The machine comes to a stop when the travel levers are not actuated.
5.5 Driving at high speed
• Driving at high speed is only possible if the switching lever
„E“ is pushed forwards. (Fig. 20)
• Operate both travel levers „FL“ and „FR“ as for normal
operation.
Note:
The roller travels at twice the speed in the „high speed“ mode.
5.6 Driving with vibration
• Vibration is switched on when the switching lever „V“ is pressed forwards or back (Fig. 21).
• If the switching lever is pushed forwards, the vibration runs „forwards“, if the lever is pushed back, it
runs „in reverse“.
• In even terrain, the switch position is of no consequence.
• However, if the machine has to negotiate an incline, the vibration be switched to the direction of travel in
order to increase the machine‘s climbing ability.
