MQ-MIKASA MRH800GS ROLLER — OPERATION AND PARTS MANUAL — REV. #5 (05/27/08) — PAGE 19
MRH800GS — HANDLE BAR/LEVER COMPONENTS
HANDLE BAR/LEVER COMPONENTS
Figure 4 illustrates the location of the major lever
components on the handle bar of the machine. Each
component is described below:
1. Travel Lever – Controls the direction of travel of the
machine (forward and reverse).
4. Horn Button – When pressed, gives a warning sound of
the machine approaching.
3. Vibration Lever – Turns vibration on and off.
4. Throttle Lever – Controls the start up of the machine.
5. Dead-Man Device – When pressed or hit while traveling
in reverse, causes the travel lever to return to neutral
position to stop the machine.
6. Light ON/OFF Switch - Turns headlight on and off.
