0 loading unloading modulus analysis example – MTS Fatigue Analyzer User Manual
Page 63
Failure Cycle Analysis Chart
6.3.4.0 Loading Unloading Modulus Analysis Example
A Loading Unloading chart plots modulus information for each test cycle. Index markers can be defined to
show the values from load start to end.
A loading unloading modulus analysis requires several variables. To access the Variable Editor, right-click
the analysis run in Explorer and select View .
To perform an analysis of modulus loading unloading:
1. Click New Cycle Marker Chart.
2. Click New Variable, type MarkerLoadingStart, and click OK.
3. Type the following values into the table.
MarkerLoadingStart
Description
Item
Loading Unloading
Category
MarkerLoadingStart
Identifier
Marker Loading Start
Display Name
0
Default Value
Count
Dimension
MTS TestSuite™ Fatigue Analyzer User Guide 63
6.0 Data Analysis
