Specifications and Dimensions
286.30 Pressure Intensifier Introduction 17
Specifications and Dimensions
The following tables list the dimensions/weights and specifications for the Model
286.30 Pore Pressure Intensifier.
Note Specifications and dimensions are subject to change without notice.
Contact MTS for verification of specifications and dimensions critical to
your requirements.
Dimensions and Weights
Parameter All Models
Height 74 in. (1880 mm)
Width 23.6 in. (600 mm)
Depth 31.6 in. (803 mm)
Weight 1000 lb (454 kg)
Reservoir Capacity 1.6 gallon (7.3 liters)
Parameter Model 286.30-01 Model 286.30-02 Model 286.30-03
Maximum Output
Pressure, MPa/PSI
Output Volume
cu. cm/in.
80/12,000
325/20
80/12,000
325/20
140/20,000
325/20
Recommended
Fluids The individual Pore Pressure Intensifier is built to be compatible with one or more
fluids. Fluids such as pure water and non-corrosive water solutions, corrosive saline
and acid solutions and refined mineral oils, such as PG
® and Multitherm ® , are used.
The 286.30-02 is the same as the 286.30-01 except it accepts a brine solution.
Use of fluids not compatible with the PPI can damage internal components.
Refer questions regarding appropriate fluid for a specific PPI to your local MTS
Service Engineer or to MTS Systems Corporation.
Maximum Fluid
Temperature 75°C/165°F for all models
Note Many triaxial cells are capable of heating pore fluid to temperatures that
exceed this value. Therefore, it is imperative that fluid from the triaxial cell
not be allowed to circulate back into the PPI while fluid temperature is above
75°C/165°F.
