How to connect cables to actuator – MTS Series 248 Actuators User Manual
Page 33
How to Connect Cables to Actuator
Series 248 Actuator Product Information
Installation
33
How to Connect Cables to Actuator
The following figures show the electrical connections of the linear variable
differential transformer (LVDT). See your controller manual for cable
specifications or cable assembly numbers.
LVDT Cable Connections
E
B
A
C
D
+EX
-EX
+FB
-FB
Yellow
Blue
Black
Red
Ground
Output
Excitation
A
C
D
E
F
B
Ground Wire
Connection
