Series 248 Actuator Dimensions
Series 248 Actuator Product Information Introduction 21
Series 248 Actuator Dimensions
Basic Cylinder Assembly Dimensional Drawing
A
4.8 mm (0.19 in)
B (min.)
248.1X, 248.2X 248.0X
F (dia.)
M (dia.)
248.0X 248.1X, 248.2X
Dynamic Stroke
C (minimum) D (cushion)
E (dia.)
4 holes, “G” thread size, “H” deep,
equally spaced on a “J” diameter
D (cushion)
8 holes, “G” thread size, “H” deep,
equally spaced on a “J” diameter
“K” thread
size, “L” deep
“K” thread size,
“L” deep
4 holes, “N” thread size, “P” deep,
equally spaced on a “Q” diameter
End Caps
(both
ends)
