Series 248 Actuator Product Information 22
Series 248 Actuator Dimensions
Introduction
Actuator Dimentions
S TROKE
A
B C D
248.0 X 248.1 X 248.2 X
MM IN MM IN MM IN MM IN MM IN MM IN MM IN
25.4 1 302.0 11.89 312.1 12.29 345.7 13.61 9.6 0.38 31.8 1.25 9.6 0.38
50.8 2 327.4 12.89 337.5 13.29 371.1 14.61 9.6 0.38 31.8 1.25 9.6 0.38
101.6 4 396.2 15.64 407.4 16.04 441.0 17.36 9.6 0.38 31.8 1.25 19.1 0.75
152.4 6 448.0 17.64 458.2 18.04 491.8 19.36 9.6 0.38 31.8 1.25 19.1 0.75
203.2 8 498.8 19.64 509.0 20.04 542.6 21.36 9.6 0.38 31.8 1.25 19.1 0.75
254.0 10 549.6 21.64 559.8 22.04 593.4 23.36 9.6 0.38 31.8 1.25 19.1 0.75
M ODEL
N UMBER
E F
G
H J
K
MM IN MM IN MM IN MM IN
248.0X 114.0 4.49 80.0 3.15 M12x1.75 mm 22.4 0.88 57.2 2.25 M27x2 mm
248.1X 133.4 5.25 100.0 3.94 M12x1.75 mm 22.4 0.88 70.0 2.76 M27x2 mm
248.2X 160.0 6.30 125.0 4.92 M16x2 mm 25.4 1.00 90.0 3.54 M36x3 mm
M ODEL
N UMBER
L M
N
P Q
MM IN MM IN MM IN MM IN
248.0X 50.8 2.00 170.0 6.72 M20x2.5 mm 23.9 0.94 136.5 5.38
248.1X 50.8 2.00 222.2 8.75 M24x3 mm 25.4 1.00 171.5 6.75
248.2X 63.5 2.50 271.5 10.69 M24x3 mm 38.1 1.50 230.0 9.06
