MTS Series 249G2 Swivels User Manual
Page 3
Series 249G2 Swivels
3
Contents
How to Get Technical Support 5
Problem Submittal Form in MTS Manuals 7
Series 249 Rod Swivel Functional Description 14
Series 249 Rod Swivel Component Identification 15
Series 249 Rod Swivel Specifications 16
Safety Practices Specific to Swivels 18
Mounting for Angularly Applied Loads 22
Checking for Swivel Bearing Backlash—Observation Method 26
Checking for Swivel Bearing Backlash—System Response Method 27
