WIRING AND BATTERY
eng
13
• Use 13 mm (6 gauge) battery cables if extending the existing wire
beyond the standard battery cable.
Recommended MotorGuide Accessory Description Part Number
Trolling motor power plug 8M4000953
Trolling motor sp (receptacle) 8M4000954
50 amp alligator clips 8M4000287
6 gauge battery cable and terminals with 50 amp manual reset
circuit breaker
MM309922T
50 amp manual reset circuit breaker MM5870
Wire Color Code Abbreviations
Wire Color Abbreviations
BLK Black BLU Blue
BRN Brown GRY Gray
GRN Green ORN or ORG Orange
PNK Pink PPL or PUR Purple
RED Red TAN Tan
WHT White YEL Yellow
LT or LIT Light DK or DRK Dark
Wire and Cable Routing
Route trolling motor wires on the opposite side of the boat from other
miscellaneous boat wiring (bow light wiring, spot light wiring, etc.).
Transducer installation should be installed according to the
manufacturer’s specifications. To avoid interference, cables should be
routed separately from the trolling motor power cables.
IMPORTANT: Do not route the transducer cable down the trolling motor
power cord or foot pedal assembly cable. Route the transducer cable
down the arm of the mount, then into the bow console.
Sensitive electronics, depth finders in particular, should be connected
directly to the main engine battery. If only a one battery system is used,
then connect with separate cables.
