MK Diamond MK-EZ Profile Milling Machine - Manual (Page 32)

32
ACCESSORIES
MK-480SDR Segmented Diamond Profile Bits
Shape Profile/Size Diameter Nut Part #
Half Bullnose B-10mm 3-1/2" 5/8" - 18 480010-18
Half Bullnose B-15mm 3-3/4" 5/8" - 18 480015-18
Half Bullnose B-20mm 3-3/4" 5/8" - 18 480020-18
Ogee F-20mm 3-1/2" 5/8" - 18 480120-18
MK-400BDB Brazed Diamond Profile Bits
Diameter Profile/Radius Diameter Nut Part #
3-1/2" A - 3/8" 3-1/2" 5/8" - 18 400038-18
3-1/2" A - 3/16" 3-1/2" 5/8" - 18 400039-18
3-1/2" B - 1/2" 3-1/2" 5/8" - 18 400012-18
4" C - 3/4" 4" 5/8" - 18 400034-18
4" E - 45° Bevel 4" 5/8" - 18 400040-18
A B C E F V
MK Diamond Profile Bits are designed to achieve a quality finish on
all profile and bevel shapes. They are for profiling tile, marble, gran-
ite, and all types of stone with superior performance and durability.
