MK-EZ PROFILER PARTS LIST
MK-EZ PROFILER ASSY, MOTOR PART # 170650
ITEM DESCRIPTION PART# OTY.
1 WASHER, FLAT, USS, 3/8 101360 4
2 SCREW, 3/8-16 X 1-1/4 HEX HEAD CAP 150774 2
3 CLAMP, CUSHION LOOP 3/8 152592 1
4 SCREW, FLAT HEAD 1-32 X 5/ 8" 153902 4
5 MTR, ELECT, 7.4 AMP 120V 156428-R 1
6 SCREW, 8 -32 X 3/8 PAN HEAD PHILLIPS 156614 4
7 KNOB, TRI PLASTIC, 1" 156770-01 2
8 FITTING, 1/4 FNPT X 1/4 BARB 162601 1
9 SCREW, 1/4-20 X 1/2 SOCKET HEAD CAP 162778 1
10 NUT, HEX, NYL, 8-32 165227 2
11 CASTING, BASE, EZPR, COMP 170656 1
12 CASTING, SLIDE, EZPR, COMP 170658 1
13 CASTING, MTR MOUNT, EZPR, COMP 170660 1
14 KNOB, 3/8-16 X 3, EZPR 170741 1
15 KNOB, 1/4-20 X 2, EZPR 170742 1
16 SPRING, EXTEN, .250 X 1.0 X .023 170743 1
17 BRACKET, BRUSH MNT, EZPR 170793 2
18 ASSY, BRUSH, EZPR 170794 1
19 FITTING, 1/4 MNPT X LOC-LINE 170797 1
20 NOZZLE, LOC-LINE, 1/8" 170798 1
