Setup, adjustment and operation – MK Diamond MK-100 JCS User Manual
Page 28
MK-100 JCS Tile Saw Revision 06/05, Effective Date June 27, 2005
SETUP, ADJUSTMENT and OPERATION
Ensure water is not forced into the motor casing when cleaning.
(K)
Clean the Movable Cutting
Table Roller Wheel Frame
Support
(J)
Clean the Movable Cutting
Table Guide Bar
(L)
Clean the remainder of the
MK-100
Clean
Guide Bar
Roller Wheel
Frame Support
