MK-100 JCS Tile Saw Revision 06/05, Effective Date June 27, 2005
UNPACKING, TRANSPORT, JCS STAND and ASSEMBLY
TABLE CLIP:
(G)
Unlock the wheel
(H)
Make sure that the wheel is
properly unlocked
(I)
Your saw is ready for transport!
(A)
Slide table to the front
(B)
Line up Clip with Side Table Slot
(C)
Swing clip over
the side of the Table
(E)
The clip secures
the Table in place
