Page 12
MK-100 JCS Tile Saw Revision 06/05, Effective Date June 27, 2005
UNPACKING, TRANSPORT, JCS STAND and ASSEMBLY
JCS STAND: Key Components for Set Up
Note: Familiarize with the following components before proceeding to SET UP.
Knob to release
Front Legs
Knob to release
Safety Arm
Handle
Cross
Member
Wheel Lock
Front Legs
Cutting Head
Handle
Table Clip
Air Springs
Front Legs
Safety Arm
