Metal Sales Metal Roofing and Siding User Manual
Page 19
Application Manual
36
Effective Date 12/08
37
c
ondition
d
etAilS
(
cont
.)
A. Hip and Valley Closure
B. Panel Fastener (3 per panel flat)
C. Cricket (field or shop fabricated - not by Metal Sales)
D. Tape Sealant (at top and bottom of Closure)
E. Cut, Bend, and Fasten (at both sides)
F. Fastener (type depends on Skylight/Chimney material)
G. Panel Fastener
H. Skylight/Chimney
I. Skylight/Chimney Flashing
J. Tape Sealant (between roof panel and trim)
K. Roof Panel
L. Cut, Bend, and Fasten (at both sides)
M. Skylight/Chimney Flashing (specify angle if not 90°)
N. Panel Fastener (1) per rib.
O. Outside Closure with Tape Sealant (at top and bottom)
A
B
D
E
F
G
H
I
J
K
L
N
M
Slope
Slope
Slope
O
See page 37 for call-outs.
c
ondition
d
etAilS
(
cont
.)
C
S
kylight
/c
hiMney
d
etAil
S
kylight
/c
hiMney
d
etAil
c
All
-
outS
