— 24 —
Table 8 — Evaporator-Fan Motor Data — High-Static Motors
LEGEND
Bhp — Brake Horsepower
*Extensive motor and electrical testing on these units ensures that the
full horsepower and watts range of the motors can be utilized with con-
fidence. Using the fan motors up to the ratings shown in this table will
not result in nuisance tripping or premature motor failure. Unit warranty
will not be affected.
Table 9 — Accessory/FIOP EconoMi$er IV Static Pressure* (in. wg)
LEGEND *The static pressure must be added to external static pressure. The
sum and the evaporator entering-air cfm should be used in conjunction
with the Fan Performance tables to determine indoor blower rpm and
watts.
Table 10 — Outdoor Sound Power (Total Unit)
LEGEND
Table 11 — Fan Performance 581B036 — Vertical Discharge Units; Standard Motor (Belt Drive)*
LEGEND
*Motor drive range: 680 to 1044 rpm. All other rpms require field-
supplied drive.
NOTES:
1. Boldface indicates field-supplied drive is required.
2. Maximum continuous bhp is 1.20.
3. See page 33 for general fan performance notes.
UNIT
581B UNIT
PHASE
MAXIMUM
CONTINUOUS BHP*
MAXIMUM
OPERATING WATTS*
UNIT VOLTAGE
MAXIMUM
AMP DRAW
036 Three 2.40 2120
208/230 6.7
460 3.0
575 3.0
046 Three 2.40 2120
208/230 6.7
460 3.0
575 3.0
060 Three 2.90 2615
208/230 8.6
460 3.9
575 3.9
072 Three 2.90 2615
208/230 8.6
460 3.9
575 3.9
COMPONENT
CFM
1250 1500 1750 2000 2250 2500 2750 3000
Vertical EconoMi$er IV 0.045 0.065 0.08 0.12 0.145 0.175 0.22 0.255
Horizontal EconoMi$er IV — — 0.1 0.125 0.15 0.18 0.225 0.275
FIOP — Factory-Installed Option
UNIT
581B ARI RATING
(decibels)
OCTAVE BANDS
63 125 250 500 1000 2000 4000 8000
036-048 76 55.9 66.0 64.0 66.2 68.4 64.5 61.7 57.3
060-072 80 59.1 68.9 68.7 71.9 74.0 68.9 65.7 59.0
ARI — Air Conditioning and Refrigeration Institute
AIRFLOW
CFM
EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts
900 567 0.15 145 688 0.22 222 786 0.30 296 871 0.37 368 947 0.44 437
1000 599 0.18 177 717 0.27 265 814 0.35 349 897 0.43 430 972 0.51 509
1100 632 0.22 215 747 0.31 313 842 0.41 407 925 0.50 498 999 0.59 587
1200 666 0.26 257 778 0.37 367 871 0.47 471 952 0.57 572 1025 0.67 670
1300 701 0.31 306 810 0.43 426 901 0.54 540 981 0.65 651 1053 0.76 760
1400 737 0.36 361 842 0.49 491 931 0.62 616 1010 0.74 738 1081 0.86 856
1500 773 0.42 422 875 0.57 564 963 0.70 699 1040 0.84 831 1110 0.96 960
AIRFLOW
CFM
EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts
900 1016 0.51 505 1080 0.57 572 1139 0.64 637 1195 0.71 702 1249 0.77 765
1000 1041 0.59 587 1104 0.67 662 1163 0.74 737 1219 0.81 811 1272 0.89 883
1100 1066 0.68 674 1129 0.76 759 1188 0.85 843 1243 0.93 925 1296 1.01 1007
1200 1093 0.77 767 1155 0.87 861 1213 0.96 955 1268 1.05 1047 1321 1.14 1137
1300 1119 0.87 866 1181 0.98 970 1239 1.08 1073 1294 1.18 1175 — — —
1400 1147 0.98 972 1208 1.09 1086 — — — — — — — — —
1500 1175 1.09 1086 — — — — — — — — — — — —
Bhp — Brake Horsepower
Watts — Input Watts to Motor
