4 programme example loop – Memmert AtmoCONTROL FDA Version 2.X.X User Manual
Page 29
D30396 | Date 09/2014
29
AtmoCONTROL FDA Version
5.4.4 Programme example loop
2
7
3
5
6
8
9
4
1
Unload
250 °C
20 °C
0% 80% 0% 80% 0% 80% 0% 80% 0% 80% 0% 80% 0% 80% 0% 80% 0% 80% 0% 80% 0% 80% 0%
1 h 1 h 1 h 1 h 1 h 1 h 1 h 1 h 1 h 1 h 1 h 1 h 1 h 1 h 1 h 1 h 1 h 1 h 1 h 1 h 1 h 1 h
2
3
5
6
8
1
4
Fig. 11
First, the appliance heats up to 250.0 °C (2) for one hour (1). Then, the fan begins to run at 80
Fig. 11
Fig. 11
% power (3) and the temperature is lowered for one hour (4) to 20.0 °C (5). Subsequently, the
First, the appliance heats up to 250.0 °C (2) for one hour (1). Then, the fan begins to run at 80
First, the appliance heats up to 250.0 °C (2) for one hour (1). Then, the fan begins to run at 80
fan is switched off (6). This sequence is repeated from the jump target (7) ten times (8).
