Page 5
5
Required for installation (not included)
- Phillips screwdriver
- Mounting pole for anemometer (optional)
- Small paper clip for reset
Installation
The Professional Weather Station TE923W-M operates at 433MHz radio frequency
, so no wire installation is required between the main unit (receiver) and the remote weather
sensors (transmitters).
The remote weather sensors include a thermo-hygrometer (temperature and humidity) sensor, UV
(ultraviolet) sensor, anemometer (wind sensor) and a rain gauge (rain sensor). All data measured
by these remote sensors is transmitted to the main unit wirelessly, with the operating range up to
328 feet (100 meters) in open area.
Remote UV sensor, anemometer and a rain gauge must be placed outdoors to measure
weather elements.
Remote thermo-hygrometers can be placed indoors or outdoors, depending on the area where the
temperature and humidity are intended to be measured. If you intend measuring outdoor
temperature and humidity, place the remote sensor outdoors.
Note: It is critical to assemble and power up all of the remote weather sensors BEFORE setting
up the main unit.
Note: It is critical to power up and test communication between all of the weather sensors and the
main unit BEFORE permanently mounting them outside.
