DI-100 User's Guide
Page: 7 / 19
P/N : 033-02205-Rev2
2 M
ODULE
D
ETAILS
2.1
External DI-100 Connection
Figure 1: Load Cell Input Port
Figure 2: Power LED & USB Host Connection
Strain Relief Bushing (included)
Cable from the load cell
Power LED
Cable to the USB Dongle (included)
