Global Drive Control | L-force Controller as Gateway
About this documentation
Conventions used
1.1 Conventions used
This documentation uses the following conventions for the distinction between different
types of information:
Type of information Writing Examples/notes
Spelling of numbers
Decimal separator Point The decimal point is always used.
For example: 1234.56
Text
Version information Blue text colour The information valid for or from one specific
software version of the controller is marked
accordingly in this documentation.
Example: This function extension is available from
software version V3.0!
Program name » « The Lenze PC software »Global Drive Control«...
Window Italics The Message window... / The Options dialog box...
Variable identifier By setting bEnable to TRUE...
Control element Bold The OK button... / The Copy command... / The
Properties tab... / The Name input field...
Sequence of menu
commands
If several commands must be used in sequence to
carry out a function, the individual commands are
separated by an arrow. Select File  Open to...
Shortcut Press to open the online help.
If a command requires a combination of keys, a "+" is
placed between the key symbols:
With + you can...
Program code
Courier
IF var1 < var2 THEN
a = a + 1
END IF
Keyword
Courier bold
Hyperlink Underlined Highlighted reference to another topic which is
activated by means of a mouse-click in the online
documentation.
Icons
Page reference ( 5) Optically highlighted reference to another page. It is
activated with a mouse-click in this online
documentation.
Step-by-step instructions  Step-by-step instructions are indicated by a
pictograph.
